Transceivers
Transceivers are ready-to-use units comprising transmit and receive functions between LANs over radio-frequency links (satellite, wireless, cable).
Burst-mode or continuous-mode of operation is supported, depending on the model. Likewise, various modulation schemes are available: PSK, spread-spectrum and continuous-phase modulations. Ancillary functions such as error correction and IP network interface are included. The underlying FPGA VHDL source code (not necessary to operate) embodied in these modems is also available for purchase.
Modules
ComBlock modules are small ready-to-use commercial off-the-shelf modules, which are configured with essential communication processing functions, including modulation, demodulation, error correction encoding and decoding, digital to analog/RF, RF/analog to digital, formatting, data storage, networking and high-speed baseband interfaces. ComBlocks are ideally suited for Software Defined Radios.
All FPGA-based modules are pre-programmed with ComBlock IP cores. Source code (not necessary to operate) can also be purchased separately.
TRANSCEIVERS
| Part number | Description | Specifications | Price | Check availability On-line purchase |
|---|---|---|---|---|
| COM-1905 | L/S-band continuous-mode PSK transceiver Connects two IP networks over a PSK link, up to 39.5 MSymbols/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
764KB | $995 | |
| COM-1918 | L/S-band continuous-mode spread-spectrum transceiver Connects two IP networks over a DSSS link, up to 39.5 MChips/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
732KB | $1250 | |
| COM-1927 | L/S-band continuous-mode CPM transceiver + TCP server modulations: FSK,MSK,GFSK,GMSK,PCM/FM,SOQPSK-MIL,SOQPSK-TG Programmable symbol rate up to 39.5 MSymbols/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
1.6MB | $995 | |
| COM-1928 | L/S-band continuous-mode CPM transceiver + IP router modulations: FSK,MSK,GFSK,GMSK,PCM/FM,SOQPSK-MIL,SOQPSK-TG Programmable symbol rate up to 39.5 MSymbols/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
2.0MB | $995 | |
| COM-1902 | L/S-band burst-mode PSK transceiver Transmits UDP frames over a PSK link, up to 39.5 MSymbols/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
1.1MB | $1250 | |
| COM-1931 | L/S-band burst-mode spread-spectrum transceiver Transmits short UDP frames over a DSSS link, up to 40 MChips/s Custom frequency band 400MHz - 3GHz Small enclosure 169x138x41mm |
1.2MB | $1250 | |
| COM-1826 | TDRSS spread-spectrum modem Digital (SDDS over GbE) or S-band RF input Up to 3 digital receivers in a 19" rack-mounted 1U chassis |
815KB | Call |
MODULES: RF / IF / BASEBAND
| COM-4009 | Digital to [400 MHz - 4.4 GHz] broadband quadrature RF modulator LVDS input |
92KB | $475 | |
| COM-4004 | 70 MHz IF modulator and frequency synthesizer [0.2 - 80 MHz] range. 14-bit precision 50Msamples/s complex input |
92KB | $345 | |
| COM-4410 | [70MHz - 2.2GHz] 4-channel quadrature RF modulators | 495KB | $345 | |
| COM-3007 | [2.3 - 2.8 GHz] & [1.15 - 1.4 GHz] Receiver, AGC, A/D converters Up to 105 MSamples/s |
690KB | $345 | |
| COM-3010 | [925 - 2175 MHz] Receiver, AGC, A/D converters Up to 104 MSamples/s |
92KB | $345 | |
| COM-3011 | [20 MHz - 3 GHz] Receiver / SDR platform |
947KB | $345 | |
| COM-3505 | Dual-band 2.4/5 GHz 2x2 MIMO transceiver | 947KB | $345 | |
| COM-3506 | [400 MHz - 3 GHz] customizable transceiver | 495KB | $395 | |
| COM-3501 | UHF frequency band [225 - 400 MHz] half-duplex transceiver Dual frequency translation, -89 dBm input, +26 dBm output For narrow-band (<400 KHz) applications |
495KB | $199 | |
| COM-2001 | Dual Digital-to-Analog Conversion 10-bit, 125 Msamples/s |
495KB | $199 | |
| COM-3504 | Dual Analog<->Digital Converters Dual 16-bit 250MS/s DACs, Dual 12-bit 150 MS/s ADCs |
495KB | $395 |
MODULES: FPGA / ARM
| COM-1800 | FPGA / ARM development platform Xilinx Artix7-100T + ARM 32-bit micro 100 MHz + DDR3 SODIMM socket + GbE LAN |
2.0MB | $445 | |
| COM-1900 | [400 MHz - 3 GHz]RF + FPGA Software Defined Radio Complete full-duplex modem hardware from RF to network interface |
499KB | $995 |
MODULES: DIGITAL SIGNAL PROCESSING / MODEMS
| COM-1805 | Continuous-mode PSK modem Fully digital BPSK/QPSK/OQPSK modem up to 39.5 MSymbols/s includes turbo-code, convolutional error corrections and LAN IP interface |
1.5MB | $445 | |
| COM-1818 | Continuous-mode spread-spectrum modem Fully digital DSSS modem, up to 39.5 MChips/s includes turbo-code, convolutional error corrections and LAN IP interface |
732KB | $445 | |
| COM-1827 | Continuous-mode CPM modem Fully digital modem: FSK,MSK,GFSK,GMSK,PCM/FM,SOQPSK-MIL,SOQPSK-TG Programmable symbol rate up to 39.5 MSymbols/s includes turbo-code, convolutional error corrections and LAN IP interface |
2.5MB | $445 | |
| COM-1802 | Burst-mode PSK modem Fully digital modem transmits UDP frames over a PSK-modulated waveform Programmable symbol rate up to 39.5 MSymbols/s includes turbo-code, convolutional error corrections and LAN IP interface |
536KB | $445 | |
| COM-1831 | Burst-mode spread-spectrum modem Fully digital modem transmits short UDP frames over a DSSS waveform Programmable chip rate up to 39.5 MChips/s includes turbo-code, convolutional error corrections and LAN IP interface |
631KB | $445 | |
| COM-1202 | PSK/QAM/APSK modem Data rate up to 22 MSymbols/s USB 2.0 interface |
779KB | $495 |
MODULES: NETWORK INTERFACE
| COM-5104 | 10G Ethernet Network Interface | 87KB | $175 | |
| COM-5102 | Gigabit Ethernet + HDMI Video In/Out Interface Card | 86KB | $145 | |
| COM-5401 | 4-Port 10/100/1000 Mbps Ethernet Transceivers | 408KB | $245 | |
| COM-5101 | Signal/Power conditioning & RS422 interface | 276KB | $245 |
MODULES: Simulators
