Overview
- L/S-band modem to connect two IP networks over a wireless, satellite or cable link. (for burst-mode see COM-1902)
- BPSK/QPSK/OQPSK modulation. Programmable symbol rate, up to 30 MSymbols/s
- RF frequency: 70 MHz – 6 GHz, -5dBm output, -85dBm sensitivity
- Convolutional + Reed-Solomon error correction + interleaving + attached sync marker
- Built-in TCP/IP server with 10/100Mbps Ethernet LAN port
- Supply voltage: 12V (included AC adapter)
- Frequency reference: internal TCXO
- Built-in tools: PRBS-11 pseudo-random test sequence, BER tester, AWGN generator, internal loopback mode.
- Monitoring:
- Carrier frequency error
- SNR
- BER
