Overview

The COM-1852SOFT is a proximity space-link modem for short-range, bi-directional, fixed or mobile radio links, generally used to communicate among probes, landers, rovers, orbiting constellations, and orbiting relays.
The modem is fully compliant with the PROXIMITY-1 CCSDS standard.
More generally, this IP core is a fairly generic PCM/Bi-Phase L/Phase Modulation modem.
The generic VHDL source code is portable to most FPGAs.

• Modulation
• PCM/Bi-Phase L/phase modulation modem, 60 deg.
• Programmable symbol rate from 1KS/s to 4096 KS/s
• Performance
• Large 160 KHz (two-sided) frequency acquisition and tracking.
• Large 1000ppm symbol rate acquisition range
• Tracking threshold Eb/N0 = 0 dB
• Built-in tools
• PRBS-11 pseudo-random test sequence
• BER tester
• AWGN generator
• Internal loopback mode
• Carrier frequency error measurement

Documentation

Specifications
Complete VHDL/IP Core license agreement

Buy

$2500 COM-1852SOFT CCSDS PROXIMITY-1 digital modem
